Farberware FW12-100024316 Toaster Oven Instruction Manual
Farberware FW12-100024316 Toaster Oven
Farberware FW12-100024316 Instructions
Here we offer the Farberware FW12-100024316 Toaster Oven manual completely free and in English. We have cataloged this manual in the Oven section on Manualverse, and it has been rated by 1 users with an average rating of 5. If you have any specific questions about Farberware FW12-100024316 Toaster Oven, we suggest checking the Frequently Asked Questions (FAQs) section of this manual.
Product Images
Farberware FW12-100024316 Toaster Oven Specifications
| Feature | Specification |
|---|---|
| Brand | Farberware |
| Product Name | French Door Air Fry Toaster Oven |
| Model Number | FW12-100024316 |
| UPC | 8-10040940439 |
| Rated Voltage | 120V ~ 60Hz |
| Rated Power Input | 1750W |
| Rated Current | 14.58A |
| Capacity | 25L, 6 slices of bread, 12 in pizza |
| Door Type | Double French-style glass doors (x2) |
| Cooking Functions | Air Fry, Toast, Bake, Broil, Roast, Pizza, Reheat, Warm, Slow Cook, Dehydrate |
| Overall Temperature Range | 100°F - 450°F (35°C - 230°C), depending on function |
| Overall Time Range | 1 minute - 24 hours, depending on function |
| Air Fry Settings | 200°F - 400°F (90°C - 200°C), 1 - 30 minutes |
| Air Fry Preset Programs | Includes A01 Fries, A02 Chicken Wings, A03 Potato, A05 Tacos |
| Toast Settings | 1 - 6 slices (default 4), browning levels 1 - 7 (default 4) |
| Bake Settings | Default 25 min / 350°F; adjustable 150°F - 360°F, 1 min - 2 h |
| Broil Settings | Default 10 min / 350°F; adjustable 150°F - 360°F, 1 min - 2 h |
| Roast Settings | Default 10 min / 350°F; adjustable 150°F - 450°F, 1 min - 2 h |
| Pizza Settings | 6, 9 or 12 in (default 9 in); default 370°F (190°C); adjustable 150°F - 450°F |
| Reheat Settings | Default 3 min / 350°F; adjustable 150°F - 450°F, 1 - 20 min |
| Warm Settings | Default 1 h / 180°F; adjustable 100°F - 300°F, 1 min - 4 h |
| Slow Cook Settings | Default 1 h / 200°F; adjustable 100°F - 230°F, 1 min - 8 h |
| Dehydrate Settings | Default 4 h / 150°F; adjustable 100°F - 200°F, 1 min - 24 h |
| Heating Elements | Upper and lower heating elements |
| Included Accessories | Oven Rack, Grill Rack, Cooking Basket, Drip Tray, Crumb Tray |
| Controls | FUNC., CONV., CONFIRM, LIGHT, TEMP/TIME, START/STOP buttons and SELECT Control Knob |
| Display Auto-Off | After 10 minutes of inactivity |
| Default Function | AIR FRY |
| Grounding | Grounded plug (3-prong) |
| Warranty | Two-year limited warranty |
| Customer Assistance | 1-855-451-2897 (US) |
Farberware FW12-100024316 Oven Details
The Farberware FW12-100024316 combines a toaster oven and an air fryer in one countertop unit with French-style glass doors. The display shows the cooking status (PREHEAT, COOKING and operation complete), the temperature, the time in hr:min, the number of toast slices or the pizza size, the browning level and a convection fan indicator. When you plug it in, the oven rings once, lights every indicator for a second, and then shows the default parameters.
Programming follows the same sequence for every function. Choose a program with the FUNC. button or the SELECT knob, press CONFIRM, turn the knob to set the temperature, then press TEMP/TIME to set the time. Turning the knob clockwise raises a value and turning it counter-clockwise lowers it. START/STOP starts or cancels a cycle. The LIGHT button turns on the interior lamp so you can check the food without opening the doors.
On Bake, Broil, Roast, Pizza and Reheat, you can turn on the convection fan during cooking with the CONV. button, and an indicator confirms it is running. The Pizza function preheats first. When preheating ends, the oven rings five times, and you then place the Grill Rack with the food inside. When any cycle finishes, the oven rings three times. The fan keeps running for about a minute afterward, so do not unplug the oven right away.
Each accessory has a specific job. The Oven Rack is for toasting, baking and cooking in metal or ovenproof glass containers, and it goes in with the convex side facing up. The Grill Rack is used with the Drip Tray, which collects food residues. The Cooking Basket sits on the Grill Rack for air frying. The Crumb Tray must stay installed whenever the oven is in use. Spread fries evenly in the basket so they cook evenly.
Before first use, remove all packaging and run the oven empty for at least 20 minutes at its highest temperature with the doors open, keeping the room well ventilated. Some odor and smoke are normal while production residues burn off. For best results, preheat the oven, cook defrosted food, and put the accessories at a height that suits the food. If food flares up, keep the doors closed, press START/STOP and unplug the unit.
The oven draws 1750W, so it should have its own wall outlet that is not shared with other appliances. Place it on a flat, heat-resistant surface away from curtains or walls, and never cover the Air Vents or the Crumb Tray with foil. Never put paper, cardboard, plastic, wood, rubber, foam or cloth inside. If you need an extension cord, use a grounded 3-wire cord with an electrical rating at least equal to the oven's.
Clean the oven after every use, once it has cooled for about 30 minutes. Slide out the Crumb Tray and empty it. Wipe the housing with a damp cloth, and clean the interior with mild detergent, taking care around the heating elements. All accessories can be washed in hot soapy water. Avoid abrasive cleaners and steel wool. The power cord wraps into the Cord Storage area at the back of the unit.
The troubleshooting guide covers common problems. If the oven does not reach the set temperature, check that the doors are fully closed. Undercooked food needs more time or a higher temperature. If toast burns, lower the browning level. The two-year warranty covers defects in materials or workmanship and provides a replacement unit. It does not cover glass parts and other wear items, commercial use, or damage from misuse. Keep your receipt to make a claim.
